Integrated ultrasonic level gauge

Product model: FST700-CS01
Product features: Non-contact continuous measurement, reducing maintenance; product 4-20mA analog output, optional alarm control, RS485/R232 communication mode; there are two options for distance measurement and level measurement; response speed is slow and medium , Quick three options can be selected...
Application scope: Basement sump, sump, pump room in building; sewage room, water plant, chemical plant, various containers and tanks, etc.; steel, coal, electric power, petrochemical, transportation, food processing and other industries.
Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
0
Introduction
Specifications
Product model

We could not find any corresponding parameters, please add them to the properties table
量  程  5~60米 防护等级  显示仪表IP65,探头IP68
测量精度  0.5%-1.0%FS 安装方式  螺纹或法兰
分辨率  3mm或0.1%(取大者) 产品功耗   一体式二线制用24V电源供电,不能带继电器,
 功耗是30mA。具体功率如下:无继电器是
 24×30mA=0.72W;一体式四线制用24V电源供
 电,不带继电器功耗是80mA,带一个继电器是要
 105mA,2路继电器130mA,具体功率如下:
 无继电器是24×80mA=1.9W;
 1路继电器是24×105mA=2.5W;
 2路继电器是24×145mA=3.1W;
信号输出  4线制4~20mA/510Ω负载
 2线制4~20mA/250Ω负载
供电电压  标配24VDC,可选220V AC±15% 50Hz
继电器输出  可选配2组AC 250V/8A或DC 30V/5A,
 状态可编程
环境温度  显示仪表-20~+60℃,探头-20~+80℃
通  信  可选485,232通信
